Frigidaire 30'' Gas Cooktop Black
Continuous Grates Move heavy pots & pans without lifting with continuous light cast iron grates.
Sealed Gas Burners Enjoy easier cleanup and a burner that stays looking great.
Low Simmer Burner Perfect for delicate foods and sauces.
Color-Coordinated Control Knobs White, Black and Bisque cooktops come with matching knobs - while Stainless Steel models feature our neutral black knobs.
Frigidaire 30'' Gas Cooktop
PRODUCT DIMENSIONS
Height 4-1/4"
Width 30"
Depth 21-3/4"
CERTIFICATIONS
ADA Compliant ADA Logo
frigidaire.com/frigidaire.ca
FFGC3026SB Frigidaire 30'' Gas Cooktop
General Specifications
PROP 65 Label Yes
Gas Connection Location Middle Right Rear
Made In USA No
Reconditioned No
Shipping Weight (lbs) 105
Power Type Gas
Size 30''
Installation Type Drop-In
Collection Frigidaire
Controls
Control Location Front
Control Type Knob
Exterior
Cooktop Finish Black
Cooktop
Warming Zone No
Installed Over a Wall Oven Yes
Grate Material Cast Iron
Left Rear 9500 BTU
Knob Color Black
Left Front 12000 BTU
Sealed Burner Yes
Electronic Ignition Yes
Right Front 15000 BTU
Number of Elements / Burners 4
Lift-up Cooktop Yes
Right Rear 5000 BTU
Bowl Type No
Cooking Surface Black
Grate Color Black Cast Matte
Knob Type Stainless Steel
Grates 2 Full-Length Grates (front to back)
Heat Source 4 Burner
Installation Type
Oven Combo Approved Yes
Electrical Specifications
Amps @ 120 Volts 5A
Dimensions: Cut-Out
Width 28-1/4" - 28-5/8"
Height 8"
Depth 19-3/8" - 19-3/4"
Certifications & Approvals
ADA Compliant - All Brands Yes
UL Listed 4-UL Certified
Agency Approval(All Brands) UL/CSA
CSA Listed Yes
Dimensions: Exterior
Depth 21-3/4"
Width 30"
Height 4-1/4"
Frigidaire 17.6 Cu. Ft. Top Freezer Refrigerator | Brushed Steel
Specifications:
Height (in) : 66 15/16"
Width (in) : 27 7/8"
Depth (in) : 30 13/16"
ENERGY STAR Certified : Yes
Height Without Hinge : 66 3/16"
Depth With Door 90? Open : 56 1/2"
Total Capacity : 17.6 Cu. Ft.
Frigidaire 25.5 Cu. Ft. Side by Side Refrigerator | Stainless Steel
General Specifications
Annual Energy (kWH): 709
Water Inlet Location Left Rear Bottom
Condenser Type Dynamic
PROP 65 Label No
Made In USA No
Power Type Electric
Size 26 Cu. Ft.
Installation Type Free-Standing
Collection Frigidaire
Exterior Dimensions
Depth with Doors and Handles 34-1/2"
Case Depth 28-3/4"
Height to Top of Door 70"
Depth 32"
Depth with Doors (no Handles) 32"
Height with Hinges and Covers 69-7/8"
Case Height 68-5/8"
Case Width 35-7/8"
Depth (with Door 900 Open) 49-1/2"
Width between Door Edges 36"
Width 36"
Height 69-7/8"
Freezer Specifications
Freezer Lighting LED
Fixed Door Bins 4 White
Full-freezer Baskets 1 Plastic
Fixed Freezer Shelves 1 Flip / 2 Wire
Dispenser
Cube Ice Yes
Water Yes
Crushed Ice Yes
Dispenser Type Tall 2-paddle
Dispenser Lock Yes
Dispenser Light Yes
Capacities
Fresh Food Shelf Area (Sq. Ft.) 16
Capacity (Cu. Ft.) 25.5
Fresh Food Capacity (Cu. Ft.) 16.5
Total Shelf Area (Sq. Ft.) 22.1
Freezer Capacity (Cu. Ft.) 9.0
Freezer Shelf Area (Sq. Ft.) 6.1
Electrical Specifications
Connected Load (kW Rating) @ 120V 1.02
Voltage Rating 120V 60Hz
Amps @ 120 Volts 8.5
Power Supply Connection Location Right Rear Bottom
Minimum Circuit Required (Amps) 15A
Exterior Specifications
Toe Grille Colormatch
Cabinet Color Colormatch
Door Style UltraSoft0
Door Stops Yes
Front Rollers Adjustable
Handle Design Color-Coordinated
Door Gasket Color Coordinated
Rear Rollers Yes
Door Finish Stainless Steel
Door Hinge Covers Hidden
Door Design Tall
Door Closers Yes
Controls
Control Location Refrigerator Interior
Controls Ready-Select0 Electronic 1-9
Water Filter Change Indicator Light No
Control Buttons 5
Weight and Dimensions
Shipping Weight (lbs) 300
Fresh Food
Humidity Controls 1
Lighting Levels Single-Level
Upper Crisper Clear
Energy Saver Plus Yes
Lower Crisper Clear
Water Filter PureSource 30
Lighting Design LED
Cantilever Shelves Yes
Fixed Shelves 2 flat edged shelves
Water Filter Location Top Right Rear
1-Gallon Adjustable Door Bins 2 Clear
Dairy Compartment Clear Dairy Door
Ice Maker
Ice Maker Type Side-Mounted
Ice Maker Yes
Certifications & Approvals
ENERGY STAR0 Certified No
ADA Compliant No
CSA Certified Yes
Frigidaire 13.9 Cu. Ft. Top Freezer Refrigerator | White
Dimensions and Volume
Height With Hinge 60 1/2"
Height Without Hinge 59 7/8"
Width 27 5/8"
Width of Cabinet 27 5/8"
Depth of Cabinet 25 1/4"
Depth With Door 29 3/8"
Depth With Door 90? Open 53 5/8"
Depth With Door and Handle 29 3/8"
Freezer Capacity 3.9 Cu. Ft.
Fresh Food Capacity 10 Cu. Ft.
Total Capacity 13.9 Cu. Ft.
